[llms-txt]: # (For AI agents: the complete documentation index is at https://developers.tetrascience.com/llms.txt — markdown versions of any page are available by appending .md to the URL.) This guide shows how to configure and use [Tetra Empower Agent](https://developers.tetrascience.com/docs/waters-empower) versions 5.4.x after an Agent is installed by using the local [**Agent Management Console**](#agent-management-console-configuration). It also describes how you can [configure Empower project settings and initiate scan requests for Empower projects remotely from the Tetra Data Platform (TDP) user interface](#tdp-ui-configuration). To install the Agent, see the [Tetra Empower Agent Installation Guide (v5.4.x)](https://developers.tetrascience.com/docs/tetra-empower-agent-installation-guide-54x). # Agent Management Console Configuration You can use the Agent Management Console to do the following: * [Configure Tetra Empower Agent settings](#configure-the-agent) * [Select which Empower Projects will be extracted](#manage-the-empower-projects-that-the-agent-scans) * [Activate the Injection Service to monitor injections as well as non-experiment summary and processing](#configure-injection-service-settings) * [Activate the Archive Service to archive Empower projects to the TDP](#configure-archive-service-settings) * [Review injection summaries to troubleshoot issues](#review-injection-summaries) To get started, do the following. ## Open the Agent Management Console To open the Agent Management Console on the host server, do the following: 1. On the Agent's host server, open **Windows Programs**. 2. In the Windows Programs menu, choose **TetraScience Agent Empower**. The Agent Management Console appears. ## Configure the Agent To configure the Tetra Empower Agent after it's installed, do the following: 1. In the Agent Management Console, select the hamburger menu icon in the left navigation menu. Then, choose **Configuration**. The Agent Configuration page appears. > 📘 NOTE > > The Configuration page provides settings to save, start, and stop the agent along with its connectivity settings to Waters Empower software and the Tetra Data Platform (TDP). This tab also provides settings to manage the Injection and Archive services as well as non-experiment data ingestion. ![](https://files.readme.io/e0867bbcddb7f304102faca280b5e72fb4e1ca030469f5d5afe229af421d82ae-empower-agent-management-cosole-v53x.png) 2. Configure the Agent by filling out the fields in the following sections on the Configuration page: * Agent Status * Empower Database * Empower Group User * Connector * Empower Agent Output Settings ### Change the Agent's Status The **Agent Status** section indicates the current state of the Agent's processing status, which can be any of the following: * **Agent Not Started** * **Running** To save, start, or stop the Agent, do the following: * To save the Agent configuration, choose **Save**. * To start the Agent after configuring new settings, choose **Start**. When the Agent starts, the status indicator shows **Running**. * To stop a running Agent, choose **Stop**. When the Agent stops, the status indicator shows **Agent Not Started**. (The Stop button can be selected only if the Agent is running.) ![](https://files.readme.io/5d7bb0f-image.png) ### Automate Status Checks by Using Windows Task Scheduler To avoid needing to check the Agent’s service status manually, it’s recommended that you create a Windows task to perform daily status checks. To create a Windows task, do the following: 1. Under **Windows Scheduled Task to check Agent Service Status**, choose **Yes**. 2. For **Run Time**, enter the time that you want the status check to run each day. If the Agent is stopped, then the scheduled Windows task restarts the Agent service automatically. If the Agent is running, it continues to run, and the Windows task will run at the time you selected. ![](https://files.readme.io/88e30b2-image.png) > 📘 NOTE > > If you manually stop the Agent, the task is removed from Windows Task Scheduler. When you run the Agent without specifying an Agent **Group User** account, the task runs under the **LocalSystem** account. ### Configure Empower Database Settings The **Empower Database User Account** provides access to the Empower Oracle Database through the Empower Toolkit and Empower libraries. The Agent does not access the Empower Oracle Database directly. Projects that can be extracted by using the Tetra Empower Agent are contingent on the access permissions granted to the **User Group** associated with the **Empower Database User Account**. For more information, see [User Account Credentials](https://developers.tetrascience.com/docs/tetra-empower-agent-installation-guide-54x#user-account-credentials) in the Tetra Empower Agent Installation Guide (v5.4.x). To provide the Agent access to your Empower Oracle Database through the Empower Toolkit and Empower libraries, you must provide the following information in the **Empower Database** section of the **Configuration** page: ![](https://files.readme.io/36daa38-image.png) > 📘 NOTE > > You can find the **Oracle Host Name**, **Service Name**, and **Port** information in the `tnsnames.ora` file on the Empower client machine. The file is typically in the following folder: `\\network\\admin\\ ` * For **Database Name**, enter the Empower database name used to log in to Empower. * For **User Name**, enter the Empower user name. * For **Password**, enter the Empower user’s password. * For **Oracle Host Name**, enter the Oracle Host name. Make sure you enter the host name as it appears in the `tnsnames.ora `file on the Empower client machine where the Agent is running. * For **Service Name**, enter the Oracle Service name. Make sure that you enter the service name as it appears in the `tnsnames.ora `file on the Empower client machine where the Agent is running. * For **Port**, enter the Oracle Port. Make sure that you enter the port as it appears in the `tnsnames.ora `file on the Empower client machine where the Agent is running. * Then, choose **Test Connection** to test the connection to the Empower Database. > 🚧 IMPORTANT > > Make sure that the Empower account used in **User Name** has the correct privileges to extract the projects. If the Agent will be used to create a Sample Set Method in Empower, more privileges may be required. Refer to the **FAQ** section for details on what privileges the Empower user needs for various data ingestion and sample set method creation functions. ### Configure the Empower Group User The Empower Group User is the user account (Windows service account) that runs the Tetra Empower Agent. It is recommended that you create a service user account specifically for the Tetra Empower Agent. > 📘 NOTE > > If you make any updates to a Tetra Agent Group User (Windows service user account) or TDP service user, you must restart the Agent for the changes to take effect. To configure the Empower Group User, do the following: 1. In the **Empower Group User** section, for **User Name**, enter the user account's user name. 2. For **Password**, enter the user account's password. > 📘 NOTE > > This user accesses the Empower File Server to fetch raw data. It's recommended that you create the user account in the same Organization Unit as Empower, so that it has the privileges required to access the Empower File Server. If the **Empower Group User** section is left blank, then the Agent assumes the **Local System** user. ![](https://files.readme.io/a50b9a9-image.png) ### Configure Connector Settings The **Connector** section on the **Configuration** tab provides settings to do any of the following: * Set the S3 Direct Upload option. * Allow the Agent to receive commands from the TDP. * Establish a data connection between the Agent and the TDP. * Specify the **Destination Id** so that files from multiple Agents can be uploaded to the same Amazon S3 bucket. (Usually, it helps to split the load into multiple agents for scaling horizontally.) * Enable or disable Injection and Archival services. #### Set the S3 Direct Upload Option To have the Agent upload files directly to your Amazon Simple Storage Service (Amazon S3) bucket, set the **S3 Direct Upload** option to **Yes**. **Yes** is the default setting for new installs. When upgrading the Agent, the setting from the previous version of the agent is retained. If you choose this option, keep in mind the following: * If you use the **S3 Direct Upload** option with a [Tetra Data Hub](https://developers.tetrascience.com/docs/introduction) that uses a Generic Data Connector (GDC), you must add an [L7 Proxy Connector](https://developers.tetrascience.com/docs/tetra-l7-proxy-connector) in the same Hub where you set up the GDC. The port of the L7 Proxy Connector must also be open. For more information, see [GDC Connections](https://developers.tetrascience.com/docs/tetra-agent-deployment-options#gdc-connections). > 📘 SQLite Database File Backups > > To have the Agent automatically perform regular backups of the SQLite database file, set the **S3 Direct Upload** option to **Yes**. When you enable this option, the SQLite database file (which stores agent configuration data) is uploaded to the backup bucket in the Tetra Data Lake. If an Agent failure occurs, you can [restore the database file from the backup bucket](https://developers.tetrascience.com/docs/restore-agent-from-backup) and continue processing. > > If you don't use the **S3 Direct Upload** option, it's recommended that you create periodic backups of the Agent database, which is typically stored in the installation folder under `C:\\TetraScience\\\db`. In the event of a failure (for example, if the host server drive is lost), this would enable the data extraction to continue from where it left off, without having to re-upload all of the data. #### Allow the Agent to Receive Commands from the TDP To allow the Agent to securely receive and [run commands](#run-commands) from the TDP, set the **Receive Commands** option to **Yes**. The default setting is **No**. #### Establish a Data Connection Between the Agent and the TDP To set up a data connection between the Agent and the TDP, enter the following information in the **Connector** section on the **Configuration** tab: > 🚧 IMPORTANT > > When establishing a connection between the Agent and the TDP, keep in mind the following: > > * Agent ID is required. > * The connection URL is required only if you're uploading RAW files to the TDP. > * Before you use your Agent ID and connection URL, it’s strongly recommended that you verify both with your TetraScience Customer Success Team. 1. For **Agent Id**, enter the Agent’s ID. The Agent ID is a Universal Unique Identifier (UUID) value that’s used to connect the Agent to the TDP. To find your Agent ID, do the following: * [Sign in to the TDP](https://developers.tetrascience.com/docs/sign-in-and-out-of-tdp-and-manage-password). * In the left navigation menu, choose **Data Sources**. Then, choose **Agents**. The Agents page appears. * In the **AGENT** column, find the name of the Agent that you’re configuring. The Agent ID is listed below the Agent name. 2. For **Connection Url**, enter the complete connection URL of the Connector or integration type that you’re using: * TDP (No Connector) URL: `` * Hub: `http://10.100.1.2:8443/generic-connector/v1/agent` * Generic Data Connector (GDC) URL: `` 3. **(For “TDP (No Connector)” setups only)** If you’re using an Agent without a Connector, make sure that you do the following: * For **Org Slug**, enter your organizational slug. To get your organizational slug, see [Viewing Organization Details](https://developers.tetrascience.com/docs/managing-organizational-accounts#viewing-organization-details). The organizational slug is required when using a JSON Web Token (JWT). Adding the slug to this field attaches it to the Agent’s API request headers. * For **Authorization**, select **Add/Edit**. In the dialog that appears, enter the JWT of the TDP service user you configured when creating the Agent. To get the TDP service user's JWT, see [Generate a JWT for a Service User](https://developers.tetrascience.com/docs/managing-organization-details#generate-a-jwt-for-a-service-user). Then, choose **Save** to encrypt and save the JWT. The Agent validates the connection immediately and displays the updated connection status next to the **Connection Url** field. > 🚧 IMPORTANT > > If the **Upload Raw Files to TDP** setting in the **Agent Run Time** section (this is described later in this page) is set to **No**, the Agent will not connect to the TDP to upload files. The status here will still show **Connected**. #### Configure Advanced Settings You can configure the following options by selecting **Advanced Settings** on the **Configuration** page: * **Data Connection status check every**: Indicates how often the software checks the status of the connection (heartbeat) between the TDP and the Agent. If the TDP doesn't receive a heartbeat message for more than five minutes, the platform assumes that the Agent is offline. The default value is `30` seconds. * **Agent log files upload every**: Indicates how often the Agent uploads log files to the Data Lake. The default value is `300` seconds. * **Proxy Settings:** Indicates what type of proxy the Agent is using (**System** or **Custom**), or if it's not using a proxy (**None**). * **System (default setting)**: Uses the system proxy specified in Windows for the service user. If basic authentication is required, you can specify a username and password for the proxy. * **Custom**: Makes all of the Agent's proxy options configurable, regardless of any other settings. This proxy takes precedence over any existing system proxy or L7 proxy. * **None**: Explicitly configures the Agent service to not use any proxies for web requests. > 📘 NOTE > > If a system proxy requires credentials, make sure that you enter them in the **Proxy Username** and **Proxy Password** fields. To keep the recommended settings, or to save the new values you entered, choose **OK**. Only consider changing these values if connection checks (heartbeat) frequency needs to be changed, or if logs files are needed to be uploaded to the TDP at a different frequency. # Enable or Disable the Injection and Archive Services You can enable two services within the Tetra Empower Agent: * **Injection Service:** Monitors Empower injections and non-experiment data and processing * **Archive Service:** Archives Empower projects to the TDP and provides the ability to restore Project Archives back to Empower from the TDP To activate the Injection Service, choose **Yes** under **Enable Injection Service**. To configure the Injection Service, see [Configure Injection Service Settings](#configure-injection-service-settings). To activate the Archive Service, choose **Yes** under **Enable Archive Service**. To configure the Archive Service, see [Configure Archive Service Settings](#configure-archive-service-settings). ## Configure Injection Service Settings The Injection Service monitors Empower injections and non-experiment data and processing, converts it to JSON format and uploads it to the TDP. To configure the Injection Service, first [enable the Injection Service](#enable-or-disable-the-injection-and-archive-services) on the **Configuration** page in the **Connector** section. Then, enter the following information in the Agent Management Console to configure the service. ### Configure Batch Size Settings Use the **Batch Size** section to set the number of Injections being processed simultaneously. The default size is **8**. As a System Administrator, you can adjust it based on the hours of the day. You can set the number up to `10` or `12`, if the host server has robust hardware specifications. You can also adjust the number lower, if the Agent consumes more CPU and memory than the host server allows. ![](https://files.readme.io/b001dbd-image.png) ### Configure Error Handling Settings To configure error handling settings for the Injection Service, enter the following in the **Error Handling** section: ![](https://files.readme.io/20c61c6-image-20231028-153215.png) * For **Continue Scan on ToolKit 105 Error**, choose **Yes** or **No**. **105 Error** is the abbreviation of an unhandled ToolKit error, `0x80010105`. This setting is to determine if the Agent should continue scanning when encountering this error. The default value is **No**. * For **Continue Generation on Toolkit Error**, choose **Yes** or **No**. This option indicates if the Agent should continue to generate the RAW JSON for an Injection if certain Empower SDK Toolkit errors are encountered, or not. * Click **Yes** to allow the Tetra Empower Agent to continue with RAW JSON generation, even if the errors occur. Please note, that this may result in incomplete RAW JSON data. The following are some of the errors that may be encountered by the toolkit during Injection generation: * `Error 105 - Error fetching Channel Chromatography data` * `Error 214 - Could not fetch requested method` * `Error 408 - Method could not be opened in the Project` * `Error 429 - LCCalibration: the requested calibration could not be fetched` * `Error 42F - An option is required in order to access this interface` * `Error 267 An option is required to open this method. Please make sure this option is enabled in the project` * `Error 40e Cannot open Method because it is being edited by another user` * If the RAW JSON is generated, the Agent will add metadata indicating the encountered error codes to that RAW JSON. > 🚧 IMPORTANT > > If you choose **Yes** for **Continue on Toolkit Error**, it is possible that, even if the errors listed above (and there may be other toolkit errors) are present, incomplete data could be copied to the RAW JSON files. If any unhandled errors occur, use this section to set the retry policies for both injection RAW file generation and injection upload. * If errors occur during extracting the Injection data from Empower, the agent will retry to extract the injection for the number of times specified in the **Injection Processing** field (or fewer times, if successful). The default value is **3**. * If errors occur during upload of the Injection RAW JSON to the TDP, the agent will retry to upload the the file for the number of times specified in the **Injection Upload** field (or fewer times, if successful). The default value is **50**. ### Configure Empower Agent Output Settings The Agent outputs RAW JSON files before uploading them to TDP. To configure the directory where the Agent outputs these files, enter the following information in the **Empower Agent Output Settings** section: * For **Output Folder**, enter the directory where you want the Agent to output RAW JSON files. * For **Required Free Disk Space (GB)**, enter the minimum required free disk space required for the Agent to process an injection. The default setting is **10** GB. > 📘 NOTE > > The free disk space refers to the output disk. When the Agent processes an injection, it first checks if the machine meets or exceeds the minimum required free disk space value. If the machine meets the required free disk space, then it processes the injection. If it does not, then the machine writes a log message while the Agent pauses and waits for other injections in progress to finish processing. The Agent then waits for files to finish uploading to the TDP before it attempts to process the new injection again. ![](https://files.readme.io/a804e5220845e1ba4d4b86d4593c6c6a74f003ddc8339ec8a277480dfa42f5e6-empower-output-folder.png) > 🚧 RAW Files May Use a Large Amount of Disk Space > > If you decide to retain the RAW files, be aware that RAW files may use most of the disk space. If the available disk space is less than what you've indicated in the **Required Free Disk Space** setting, then the Agent will pause the Injection generation. Use the **Injection Summary** page to check the available disk space. ### Configure Agent Run Time Settings You can use the **Agent Run Time** section to configure the following: * Set the Agent to upload the RAW files to the TDP. * Set to keep RAW files in the local drive after the files are uploaded successfully. * Set the **Data Precision Specification** option when ingesting the injection data from Empower. * Set the scan interval in minutes for how often the **Tetra Empower Agent** periodically scans Empower projects to detect new or reprocessed injections. * Set advanced properties, such as the number of processes you want to use to generate injections, scan time interval, and generation timeout. ![](https://files.readme.io/1f524a6b99c13df86677e0fedf28f28ccdb79004f3b80f23d2be5a439063b8b1-empower-management-console-agent-run-time.png) To configure **Agent Run Time** settings, do the following: * If you set the **Upload Raw Files to TDP** field to **Yes**, then the **Keep Local RAW File After Upload** field is automatically set to **Yes**. If you set the **Upload Raw Files to TDP** field to **No**, the Agent will not connect to the TDP and only generate files to store them locally. * If you set the **Keep Local RAW File After Upload** field to **No**, then the RAW files are deleted from the output folder after the RAW files have been successfully uploaded to the TDP. * If you set the **Data Precision Specification** to **Empower**, the data (Peak, Result, and Sign-Off data) extracted from Empower Software follows the precision set in the Empower Client. If **Oracle** is selected, data precision is maintained up to 17 decimal places. #### Configure Agent Run Time Advanced Settings The **Advanced Settings** option in the **Agent Run Time** section provides settings to manage scan, generation, and upload throughput. These are advanced options, and the recommended settings are included as default values. ![](https://files.readme.io/c8172d65c850fe244af48d9fb1a9aef097d9d60b1cec25d2143a2a7d4861e14a-run-time-advanced-setting.png) * **Normal Generation Process #**: The agent can prioritize injections based on when they have been created/modified (more details in the next section). This setting provides the number of processes the agent will allocate to injections that are assigned **Normal** priority. This setting leverages the hardware of machines that have multiple cores, which allows you to specify how many processes you want the Tetra Empower Agent to use to generate Empower injections. Each process handles one project at a time; specifying several processes allows the Tetra Empower Agent to process several projects in parallel and expedite processing time. The default value is **2**. * **New Injection Generation Process #**: The agent can prioritize injections based on when they have been created/modified (more details in the next section). This setting provides the number of processes the agent will allocate to injections that are assigned **High** priority (these are recently created or modified injections that will be generated before historical/older injections). This setting leverages the hardware of machines that have multiple cores, which allows you to specify how many processes you want the Tetra Empower Agent to use to process Empower injections. Each process handles one project at a time; specifying several processes allows the Tetra Empower Agent to process several projects in parallel and expedite processing time. The default value is **1**. * **3D MS GetSpectra Generation Process #**: The agent provides an option to specify how 3D MS data cubes will be generated for every project (see Project tab settings later in this document for more details). If for a selected project, the **3D MS Method** is specified as **GetSpectra**, then any injection in that project (irrespective of priority) will be processed by processes defined here. This setting leverages the hardware of machines that have multiple cores, which allows you to specify how many processes you want the Tetra Empower Agent to use to generate Empower injections. Each process handles one injection, which contains a 3D MS channel, at a time; specifying several processes allows the Tetra Empower Agent to process several 3D MS injections in parallel and expedite processing time. The default value is **1**. > 🚧 Optimize for Your Empower Infrastructure > > The ability of the processes from these three generation processor settings, along with the injection scan, injection upload, and non-experimental generation processes (if configured), to perform optimally will depend on the virtual machine (VM) that is set up for the Agent. During testing, six or 10 processors were adequate when running Empower Services on a small instance, **t2.large**. However, that may depend on your Empower Services needs (for example, how many concurrent sessions it should support, the load of each session, and so on). > > Make sure that the instance(s) running the EmpowerDB and Empower file server can sustain the load from the set Generation Processes. Using too many processes may increase the risk of overloading the instance(s) and reduce their service availability. * **Normal Project Scan Process#**: This setting provides the number of processes the agent will allocate to scan the projects that are assigned as **Normal** priority. The default value is **1**. * **High Project Scan Process#**: This setting provides the number of processes the agent will allocate to scan the projects that are assigned as **High** priority. The default value is **1**. * **Upload Max Parallelism #**: Provides the setting for maximum parallel processes for upload. The upload continuously processes generated RAW files and this instructs the agent how many processes to use. The default value is **(total CPU cores available -1)**. * **Max Number of Projects Per Scan Process** - Instead of scanning all of the projects in one process, the Agent separates the whole list into multiple batches with a default size of **20**. This size may be set to 1 to improve reliability, but it will introduce some overhead. * **Scan process Timeout (minutes)** -This setting is to prevent the scan process from hanging due to unhandled Empower ToolKit errors. The default is **600 minutes**. If you change the setting of **Max Number of Projects Per Scan Process**, you might need to adjust this setting as well. Please consult your Tetra support engineer. * **Generation process Timeout (minutes)** - This setting is to prevent the injection generation process from hanging due to unhandled Empower ToolKit errors. The default is **600 minutes**. * **Non-experiment process Timeout (minutes)** -This setting is to prevent the Non-experiment data extract process from hanging due to unhandled Empower ToolKit errors. This setting is applied for all four types of Non-Experiment data extraction, “Extract System Audit Trail“, “Extract Project Audit Trail“, “Extract Message Center“ and “Extract Project/User Access Permission“. * **Project prioritization process Timeout (minutes)** - The Tetra Empower Agent has a dedicated process to determine the project priority. This setting specifies a timeout value to restart the process to reduce the impact of the unhandled Empower ToolKit errors. * **Batch size of the project priority scan** - Similar to other scan processes, the Tetra Agent tries to process the project scan in batch to reduce the potential impact of ToolKit unhanded errors. The default size is **100**. * **Injection Generation Max Timeout (minutes)**: This setting is used for injections where there are no 3D MS data cubes or has 3D MS data cubes but the 3D MS generation method is not GetSpectra at the project level. This is the maximum time the agent will use to generate an injection (once it has started the generation process for the injection). If the injection cannot be generated in the specified time, an error is logged (consider increasing the time if there are such errors). The default value is **60 minutes**. * **Injection Generation Retry Timeout (minutes)** - This setting is applied when injection generation fails and the Tetra Empower Agent needs to retry the generation. The default value is **180 minutes**. * **Injection GetSpectra Generation Max Timeout (minutes)**: This setting is used for injections where there are 3D MS data cubes and the 3D MS generation method is GetSpectra at project level. This is the maximum time the agent will use to generate an injection (once it has started the generation process for the injection). If the injection cannot be generated in the specified time, an error is logged (consider increasing the time if there are such errors). The default value is **180 minutes**. * **Enable Empower Connection Status Check** - The default is **Yes**. The Agent checks the Empower connection periodically. If it doesn’t connect successfully, the Agent will terminate the processes to scan or generate the injection. It improves the reliability by avoiding processes hanging due to Empower errors. * **Interval for Empower Connection Status Check (minutes)**: The time interval to run the Empower Connection check. > 📘 NOTE > > The following scan job interval settings are available for **Tetra Empower Agent v5.4.x** and higher only. These settings regulate how frequently the Agent has access to the Empower server to detect changes. Configuring scan job interval settings can help reduce database connection requests and prevent excessive overhead on the Empower server while maintaining the same data latency. * **Normal Priority Scan Interval (seconds):** The time interval to scan normal priority projects. The default is **60 seconds**. * **High Priority Scan Interval (seconds):** The time interval to scan high priority projects. The default is **60 seconds**. * **Project Priority Scan Interval (seconds):** The time interval for executing the process that determines project priority. The default is **60 seconds**. > 📘 NOTE > > The following settings are available for **Tetra Empower Agent v5.4.1** and higher only. * **Normal Priority Scan Throttle (Seconds):** The wait duration (in seconds) introduced between individual project scans within the Normal Priority scan job. Use this setting to reduce spikes in server load during scanning. The default is **0** seconds (no throttle). * **High Priority Scan Throttle (Seconds):** The wait duration (in seconds) introduced between individual project scans within the High Priority scan job. Use this setting to reduce spikes in server load during scanning. The default is **0** seconds (no throttle). * **Project Scan Throttle (Seconds):** The wait duration (in seconds) introduced between individual project scans within the Project Prioritization scan job. Use this setting to reduce spikes in server load during project prioritization. The default is **0** seconds (no throttle). * **Enable Normal Priority Project Scan Job:** When set to **No**, the Normal Priority scan job does not run after the Agent starts. The Agent always performs an initial scan on startup regardless of this setting. The default is **Yes**. * **Enable High Priority Project Scan Job:** When set to **No**, the High Priority scan job does not run after the Agent starts. The Agent always performs an initial scan on startup regardless of this setting. The default is **Yes**. ### Configure Injection Generation Boundary Parameters Settings The **Injection Generation Boundary Parameters** section is designed as a fail-safe should Empower indicate that the injection processing hangs in the incomplete state, even though it actually is complete. ![](https://files.readme.io/9618b27-image.png) The **Injection Generation Boundary Parameters** section includes the following settings: * **Maximum Acquisition Duration**: Indicates how long the Tetra Agent should wait before uploading an incomplete injection processed file. If the injection remains incomplete, the agent will keep scanning and waiting until the injection reaches complete status or reaches the **Maximum Acquisition Duration** hours after the **Last Modified Date** of the Channel RAW data file. > 📘 NOTE > > The default value for the **Maximum Acquisition Duration** is **72** hours, which is the maximum amount of time that the LAC/E can hold the data in buffering mode. You can adjust this number to accommodate needs specific for your infrastructure. This value can be configured to be any integer from **1** to **150**, but we strongly recommend that this value not be less than 72 hours to match the LAC/E buffering duration. * **Tolerance Percentage**: Run Time Tolerance is used when comparing the injection run time with the range of timestamps in the injection data. This comparison is used to determine whether an injection has completed or is still in progress, and is only used in versions of Empower where the injection completion status is not available. The actual duration of data collected may not exactly match the planned injection run time, so this configurable tolerance is used in the comparison. If the difference between the last timestamp and the injection run time is in the range of the tolerance percentage, the injection is considered complete. The default value of Run Time Tolerance is **1%** and can be set up to **50%**. This field is used for Empower 3 Pre-SR3 implementations only. > 📘 NOTE > > To avoid Data Integrity issues, the Agent will not generate the RAW JSON file until the acquisition process is finished. > > * For Empower SR3 and above, the Agent uses the injection status and channel status to determine when injection information is complete. > * Pre-SR3, the Agent uses the injection runtime and the datacube timestamp to determine when injection information is complete. * **Prioritize Injections created/modified in last (hours)**: Provides the option to specify the number of hours, which the Agent will use to identify any injections that have been created or modified in that window back from now. These injections will be assigned high priority and will be generated before other injections with normal priority are generated. The number of processes used to generate these injections (and the project containing those injections) is defined in **Agent Run Time** → **Advance Settings**. The default value is **72 hours**. We recommend that you keep this value the same as the **Maximum Acquisition Duration** setting. ### Configure Non-Experiment Settings To extract and review processing summaries for non-experiment data, configure the following settings in the **Non-Experiment** section: ![](https://files.readme.io/f343221-image.png) The Empower Agent can generate RAW files from the following Empower data streams: * System Audit trails * Project Audit trails * Message Center logs * Empower Project/User Access permission Choose **Yes** for the data stream you want to extract. Non-experiment data shares the same configuration settings as Injection data for uploading to the TDP, and retaining generated data locally. The **Time Interval (minutes)** setting can be configured to specify the frequency of generating the non-experiment data. The default value is **60 minutes**. ### Manage the Empower Projects That the Agent Scans To manage which projects from Empower the Agent scans and generates, select **Project** from the left navigation menu. A list of your Empower projects that the Agent's **Empower User** can access appears. ![](https://files.readme.io/554f338-image_6.png) Projects are arranged in alphabetical order, maintaining the parent-child relationship that is set up in Empower. When new Empower projects are added, the Agent detects them from its periodical scan job and adds those new projects to the **Project list** automatically. One Empower Database can contain hundreds to thousands of projects. You can select the projects you want to process. As a System Administrator, you can select which projects the Agent uses to generate the RAW files. Additionally, the Agent constantly monitors any project changes to detect new and updated Injections. > 🚧 IMPORTANT > > If the Agent scans an Empower project that has a path with more than 260 characters (the [`MAX_PATH` limitation for the Windows API](https://learn.microsoft.com/en-us/windows/win32/fileio/maximum-file-path-limitation?tabs=registry)), the Agent won't record that the file upload succeeded. This behavior results in a race condition that causes the Agent to continue re-uploading the same file, without recognizing that each following upload attempt is also successful. Please contact TetraScience support if you encounter this issue. You can configure any of the following on the **Project** page: * **Save**: After making any configuration changes, remember to save settings. * **Refresh** : Refreshes the list of projects manually. * **Auto Enable New Project**: Select the **Auto Enable New Project** check box to have the Agent extract the Injections automatically from the projects added to Empower. This feature applies only to those projects that were added or imported to the Empower Agent after you changed and saved the check box setting. * **Auto Enable New Child**: When this option is selected, the newly added project will be enabled automatically if its parent project is enabled. Also, the newly added project will inherit the **Sign Off Result Option** and **3D MS Method** from its parent project. When the **Auto Enable New Project** is selected, the **Auto Enable New Child** option is selected automatically. * **Enabled**: This selection box allows you to manually select or unselect which projects the agent should scan and extract data from. If a project is unselected which injections from it are being generated, the agent will complete generating all injections from it at that time. Subsequently the project will not be scanned and any new or modified injections will not be generated. * **Project** : Shows the Empower project name. * **Generation Status**: Shows the generation status of the project. The Generation Status has the following possible states: * **No Injection**—Project is not selected. * **Pending Generation**—Project is selected but has not been processed yet. * **Generation In Progress ( x )**—Injections in the project are processing. The **X** percentage is calculated from the count of total injections and the number of injections have been generated. * **Generated**—Injections in the project have been processed completely. If it is in the middle of processing, it will show how many percentages of total Injections have been processed. * There can also be other error messages which are returned from ToolKit during injection scanning. * **Priority**: Shows the scan priority assigned to the project. If there are any injections for a project that have been modified within the time provided in Prioritize Injections created/modified in last (hours) setting, the priority is **High**, else the priority is **Normal**. Based on the priority, there are dedicated processes to generate the injections (see **Configuration** → **Agent Run Time** → **Advanced Settings** for details). * **Set Priority** - As a System Administrator, you can explicitly set the project priority. When this checkbox is checked, the associated **Priority** field will turn into a dropdown with values as **High** and **Normal**. It overwrites what is calculated by the Agent. When the user unchecks this field, the Agent will use the priority calculated by the Agent. * **Last Scanned**: Shows the date and time when the project was last scanned by the agent. * **Sign Off Result Option**: Provides settings to manage if injection data will be generated by an agent based on sign offs performed in Empower. These are the available options that you can select for the Sign Off Result Option for a project (default is **Not Required**): * Not Required * Level 1 Required * Level 2 Required * **3D MS Method**: Provides settings to configure which toolkit method will be used to generate 3D MS data cubes, if any injection for the selected project has them. The options are (default is **Get3D**): * **None** : No 3D MS data cubes will be generated by an agent even if an injection contains that data in Empower * **Get3D**: Will use Get3D toolkit method to generate the 3D MS data cubes. This may result in data that is not precise as Get3D “bins” the results and rounds them. * **GetSpectra**: Will use the GetSpectra toolkit method to generate 3D MS data cubes. This will provide the most precise data from Empower for 3D MS. However, please note this method will be slower to generate the injection. Dedicated process(es) will generate 3D MS with GetSpectra method. The number of processes used for this is defined in **3D MS GetSpectra Generation Processor #** setting. Refer to FAQs to know more about the difference between Get3D and GetSpectra methods for 3D MS data cubes. ### Review Injection Summaries To re-upload project data or to review a summary of injection processing, injection processing errors, and system health metrics, choose **Injection Summary** in the left navigation menu. The Injection Summary page appears. #### View Project Data and Re-Upload ![](https://files.readme.io/7f178c0-image.png) The dropdown shows **All Projects** option as well individual project names, which the Agent has scanned and found injections to be generated. The **Processing Summary** (see next section for details) shows the injection processing summary for the selected project. If **All Projects** is selected, then **Processing Summary** will show data for all projects that the Agent has processed. The **Rerun Project(s)** button allows you to re-upload data for selected projects. This will open a project tree to select one or more projects. The projects displayed here are those which are selected in the **Project** tab and that the Agent has already generated injections for. The projects list is alphabetically ordered and will have parent-child tree similar to how it is displayed in the **Project** tab. Choose **OK** to re-upload all the injections for the selected projects. All projects may be re-uploaded using this option. ![](https://files.readme.io/8178ea4-image.png) #### View a Processing Summary The **Processing Summary** shows the scan, generation, and upload status of injections for a selected project (or all projects). ![](https://files.readme.io/1fabe38-image.png) The Processing Summary displays the following information: * **Scanned Injections**: Number of Injections scanned by the agent * **Pending Generation**: Number of Injections that have been scanned but not generated yet by the agent * **3D MS w/ GetSpectra**: Number of Injections which have 3D MS data cubes, and corresponding 3D MS Method in project is GetSpectra, that have been scanned but not generated yet by the agent * **Generated**: Number of scanned Injections for which that RAW files generated * **Failed to Generate**: Number of scanned Injections that failed to generate a RAW file * **Pending Upload**: Number of generated Injections waiting to be uploaded to the agent * **Uploaded**: Number of Injections that have been uploaded to TDP successfully * **Failed to Upload**: Number of Injections that the agent failed to upload to TDP * **Last Refresh**: Timestamp of latest Injection processing summary displayed in local time #### Review Injection Generation Error and Injection Upload Errors To review injections that were scanned but couldn't be generated because of an error, look at the **Injection Generation Error** tab. ![](https://files.readme.io/738364e-image.png) To review injections that were generated, but couldn't be uploaded to the TDP because of an error, look at the **Injection Upload Error** tab. ![](https://files.readme.io/6009302-image.png) To regenerate and re-upload the failed injections manually, select a row in the grid and click **Regenerate failed injections** or **Reupload failed injections** in the appropriate grid. To help identify and troubleshoot duplicate injection scans, the Agent automatically generates a list of any duplicated injections in each scan during the Agent installation and uploads it to the Agent's installation folder as an `injections_to_be_removed.json` file. Do not delete this file. You can review the `injections_to_be_removed.json` file to identify any duplicate injections, and then send it to TetraScience for troubleshooting by [submitting a support ticket](https://developers.tetrascience.com/docs/support-request#/). #### Review System Messages The Tetra Empower Agent generates host server system metrics every minute and provides the following metrics: ![](https://files.readme.io/e4911f1-image.png) * Available Disk Space (in GB) * Disk Usage (as a % of the total) * CPU Usage (as a % of the total) * Memory Usage (in MB) * Available Memory (in MB) * Upload Error Rate * Scan Access Rate * Data Connection (connection status between the Agent and the TDP) > 📘 CPU Usage Percent is 0% > > If the **CPU Usage Percent** shows 0%, then the user account that was defined as an **Empower Group User** was not included in either the Administrators group or the Performance Monitor Users group. ![](https://files.readme.io/a06e61b-image.png) ### Review Non-Experiment Summaries The **Non-Experiment Summary** section's **Audit Trail** tab displays the details audits the agent has extracted. ![](https://files.readme.io/b46b148-image.png) The project name is applied to ProjectAuditTrail type. For SystemAuditTrail and MessageCenter, the Agent uses the Empower Database Name. Additional data fields include the following: * Type * Message * Total Generated Records * Last Process Time * Latest log (in JSON format) The **Project/User Access Permission** tab includes its own summary page, where you can review its **Project Status**, **Last Process Time**, and any **Messages**. ![](https://files.readme.io/79437d0-image-20231026-163209.png) Empower Agent scans projects periodically. When the Agent detects any changes from Empower Project, User, User group, User type, or the methods, the Agent generates a JSON file containing all of the Empower users, user types, and projects and method names with their associated user groups. > 📘 NOTE > > The Empower Agent now has a **Clear Cache** button to clean up the local cache of Project User Permission data. This causes the Agent to generate the data from scratch rather than incrementally. It is useful when the local state is in an invalid state and is preventing the Agent from extracting the data from Empower. You can find which events trigger file regeneration and re-upload in this [section](https://developers.tetrascience.com/docs/faq-1#what-events-trigger-the-agent-to-regeneratereupload-the-projectuser-access-permission-data) of the FAQ. > 📘 NOTE > > If you store Non-Experiment data in the local drive, it is moved to an Archive folder under the following directory: `\\\\\` ## Configure Archive Service Settings The Archive Service archives Empower projects to the TDP and provides the ability to restore Project Archives back to Empower from the TDP. When the Archive Service's **Auto Archive** option is activated (set to **Yes**), the Agent archives Empower projects by following a predefined workflow determined by the **Archive Run Time Settings** that you configure during installation. When deactivating this option (set to **No**), the Agent won't archive Empower projects automatically, but users can still [archive Empower projects manually](#manual-archive). If a project remains inactive for a specified number of days, the Agent imposes a five-day lock on the project. Then, if no activity occurs within this frame, the Agent initiates the [archiving process](#auto-archive-workflow) for that project. After the backed up project is uploaded to the TDP, the project and its [labels](#project-level-labels) become searchable within the TDP. To configure the Archive Service, first [enable the Archive Service](#enable-or-disable-the-injection-and-archive-services) on the **Configuration** page in the **Connector** section. Then, activate the **Auto Archive** feature by doing the following: > 📘 NOTE > > The **Auto Archive** feature is applicable to all accessible Empower projects under the Tetra Empower Agent's **Empower Database user** account. 1. Open the Tetra Empower Agent **Management Console**. Then, in the left navigation menu, under **Menu**, choose **Configuration**. 2. In the **Connector** section, make sure that the **Enable Archive Service** option is set to **Yes**. 3. Select the **Archive** tab. 4. In the **Archive Run Time** settings section, for **Auto Archive Enabled**, select **Yes**. 5. Configure the remaining **Archive Run Time** settings. ![](https://files.readme.io/9de5b50-archive-service-configure.jpg) The following settings are available on the **Archive Run Time** tab: * **Auto Archive Enabled**: The Agent offers support for both manual (ad hoc) archive and automatic archive. When the **Auto Archive** option is activated (set to **Yes**), the Agent archives Empower projects by following a predefined workflow determined by the Archive Run Time Settings that you configure. When deactivating this option (set to **No**), the Agent won't archive Empower projects automatically, but users can still archive Empower projects manually. * **Automatically archive Empower projects if they have been inactive for x days since the last modified date**: This option is activated when **Auto Archive Enabled** is set to **Yes**. Once activated, the Archive service applies **read-only** locks on any Empower projects that have not been updated for the number of days specified. For example, you could set _180_ for this rule, and old projects that have not been updated for at least 180 days will be locked as automatic archive candidates. The Archive service would then periodically scan all available projects for archive candidates. > 🚧 IMPORTANT > > The Archive service relies on the full Audit Trail for each project to determine its last change date. Projects with Audit Trail turned off will not be eligible for automatic archive. * **Grace Period for lock-down**: This option is activated when **Auto Archive Enabled** is set to **Yes**. This rule makes the Archive service hold off the archive operation after projects are locked as archive candidates from the step above. During this grace period, projects that incur changes will not be archived. The project will then be put back to the project list and will be processed during the Agent's next scan. In the example shown above, you could set _5_ days as the grace period, and then projects, which are locked from the prior step, will not be archived until the end of the five-day grace period. * **Anchor Project Name**: The Agent requires a valid and unlocked project to access Empower during archive or restore operations. It's recommended that you dedicate a project in Empower for this purpose. This project won't be auto archived. * **Max retry times**: You can specify the maximum retry count when the archive or restore fails because of any exception. * **Archive Advanced Settings** ![](https://files.readme.io/ef1d509-archive-service-configuration-advanced-setting.jpg) * **Archive Auto Scan Interval In Hours**: Determines the frequency of project scans. The default value is set to `24` hours, meaning that the Agent will not scan Empower for project changes if it has been less than 24 hours since the last scan. * **Archive Project Refresh Command Timeout In Minutes**: Determines the timeout duration (in minutes) for the Agent to detect the new projects from Empower. The default time is `600` minutes. * **Archive Project Auto Scan Command Timeout In Minutes**: Specifies the timeout duration (in minutes) for the Agent to scan projects in Empower and detect any changes. The default duration is set to `600` minutes. * **Archive Project Backup Command Timeout In Minutes**: Specifies the timeout duration (in minutes) for backing up a project in Empower. The default time is set to `600` minutes. * **Archive Project Restore Command Timeout In Minutes**: Specifies the timeout duration (in minutes) for restoring a project in Empower. The default duration is set to `600` minutes. * **Default Archive Comment**: Defines the comment that may be necessary for Empower when archiving or restoring the Empower project. > 📘 NOTE > > The Archive service makes sure that any of the archived project's child projects are archived before the parent projects. The Tetra Empower Agent initiates the archiving process starting from the leaf-level projects, and then recursively works upward until reaching the top-level project. ### Auto Archive Workflow > 🚧 IMPORTANT > > If an Empower project has a **Full Project Lock**, the Agent will set the Auto Archive status to **Failed**. If this occurs, you must either remove the Full Project Lock or [archive it manually](#manual-archive). For instructions on removing the lock, see [How to lock projects and sub-projects in Empower](https://support.waters.com/KB_Inf/Empower_Breeze/WKB465_How_to_lock_projects_and_sub-projects_in_Empower) in the Waters Knowledge Base. When **Auto Archive** is activated, the following workflow occurs for each project that's archived. | Workflow Status | Description | | :---------------- | :------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------ | | `Open` | Starting state.
The Empower project is active, or the remaining inactive days have not yet exceeded the configured limit. | | `Locked` | The project remains inactive beyond the configured limit, but is still within the grace period. | | `Extracting` | Empower project backup started. | | `Verifying` | Confirming data integrity of the backed up Empower project.
If the project encounters any data integrity error, the Agent will change its status to `Integrity Error`. | | `Uploading` | Backed up project is loading to the TDP.
The Agent uploads the compressed archive project, including the MD5 checksum of the compressed files along with other [project-level labels](#project-level-labels) | | `Deleting` | The project is being deleted from Empower after it is successfully uploaded to the TDP. Before deletion, the Agent queries the TDP `FileInfo` API to fetch and verify the [project-level labels](#project-level-labels) to make sure that the archive project is uploaded to the TDP. | | `Succeeded` | The project backup or restore succeeded. | | `Integrity Error` | The project to archive contains a data integrity error.
The user can **Restart** the archive by ignoring the data integrity errors. | | `Failed` | The project is failed to be archived or restored | ### Exclude A Project from Auto Archiving To exclude an Empower project from being automatically archived, do the following: 1. Open the Tetra Empower Agent **Management Console**. Then, in the left navigation menu, under **Menu**, choose **Archive Service**. 2. Choose **Project**. The Project tab appears. 3. Find the name of the project that you want to exclude from archival. Then, on the far right of that project's row, select the **Exclude** button. ![](https://files.readme.io/b1436e0-archive-service-project-excluded.jpg) ### Manually Archive a Project > 📘 NOTE > > Manually archived projects undergo the same workflow as **Auto Archive** projects in terms of **Extracting**, **Verifying**, **Uploading**, and **Deleting**. To manually archive Empower projects, do the following: 1. Open the Tetra Empower Agent Management Console. Then, in the left navigation menu, under **Menu**, choose **Archive Service**. 2. Choose **Project**. The Project tab appears. 3. Find the name of the project that you want to manually archive. Then, on the far right of that project's row, select the **Archive** button. The project's status changes to **Submit to Archive**, and the project is added to the Agent's archive processing queue. > 🚧 IMPORTANT > > To manually archive a parent-level Empower project that has child projects, you must first archive the child projects. Empower doesn't allow orphaned child projects, so the archival of the parent-level project will fail otherwise. ![](https://files.readme.io/c057516-archive-service-project-manual-archive.jpg) > 🚧 IMPORTANT > > The Agent will be unable to archive the project if the combined length of the Agent's **Output** folder path and the full project path exceeds **240** characters. ![](https://files.readme.io/1e62e60620e77aaee152634eafc9d0e4339026fd0926343ca15d522e9086e1ee-archive-service-long-path-error.png) ### Restore an Archived Project To restore an archived Empower project from the TDP to Empower, do the following: 1. Get the project's TDP `File ID` by doing one of the following: * In the Archive service's **Project** tab in the Tetra Empower Agent Management Console, find the project that you want to restore. Then, in the **Message** column for that project, copy the `File ID` that's listed. ![](https://files.readme.io/5a6dbc9-archive-service-succeeded-file-id.jpg) ``` \-or- ``` * [Search](https://developers.tetrascience.com/docs/search-tdp) for the archived Empower project in the TDP. Then, open the [File Details page](https://developers.tetrascience.com/docs/search-tdp#view-the-file-details-page) for the project and copy the `File ID` that's listed. ![](https://files.readme.io/875bfbc-archived-project-tdp-3.jpg) 2. Open the Tetra Empower Agent Management Console. Then, in the left navigation menu, under **Menu**, choose **Archive Service**. 3. Choose **Project**. The Project tab appears. 4. Select the **Restore** button. The Restore dialog appears. ![](https://files.readme.io/d76ac65-archive-service-restore-prepare.jpg) 5. For **Enter your backup project file id here**, enter the project's `File ID`. Then, choose **Restore**. ![](https://files.readme.io/6d657c1-archive-service-restore-restore-key-1.jpg) 6. Review the restored project's information. Then, choose **Submit**. > 📘 NOTE > > If there isn't enough space on the local drive to accommodate the downloaded and uncompressed project, the restore request cannot be submitted. When this occurs, the Agent rechecks the available space after the archived project is downloaded. > If there still isn't enough space, the restore process fails. > ![](https://files.readme.io/2faf5bd-archive-service-restore-insufficient-disk-space.jpg) 7. View the details of the restore process by opening the Archive Service's **Summary** tab for processing details. After choosing **Submit** on the Restore action, the project status changes to **Submit to Restore** and the project is added to the Agent's restore processing queue. If there is any application error or project data integrity issues, the Agent marks the status as **Failed**. #### Restored Project File Names Based on the restored project's state, one of the following naming conventions is appended to the project's file name after its restored to Empower: * For a restored project, the Agent appends `(restored)` to the project name. For example, if a project's original name is **Tetra_Test**, the Agent suggests the restored project name as `Tetra_Test(restored)`. ![](https://files.readme.io/a4dc739-archive-service-restore-restore-verification.jpg) * If a project has been previously restored, the Agent appends a counter to the project name, such as `Test321(restored)2` in the **Project Path** field. ![](https://files.readme.io/21b7781-archive-service-restore-restore-count.jpg) * If a project with the same name already exists, the user is prompted to select a different project name. ![](https://files.readme.io/925a3d1-archive-service-restore-restore-same-project-name.jpg) ### Manage Transactions You can can review all transactions related to archive or restore processes from the Archive Service's **Summary** tab in Tetra Empower Agent Management Console. You can also use the **Summary** tab to **cancel** archive or restore operations, or **restart** failed operations. To access the **Summary** tab, do the following: 1. Open the Tetra Empower Agent Management Console. Then, in the left navigation menu, under **Menu**, choose **Archive Service**. 2. Choose **Summary**. The Summary tab appears. ![](https://files.readme.io/87abf2e-archive-service-summary.jpg) #### View Transactions To view details about a specific archive or restore process, select the process in the **Summary** page. A dialog appears that displays detailed operational activities for each transaction. **Successfully Archived Project Example** ![](https://files.readme.io/efbdd0e-summary-success.jpg) **Failed Project Restore Example** ![](https://files.readme.io/ac4ee67-summary-failure.jpg) #### Cancel an Archive or Restore Process To cancel a running archive or restore process, select the **Cancel** button in that transaction's row on the **Summary** tab. You can cancel processes that are in the following statuses: * **Submit to archive** (Archive) * **Locked** (Archive) * **Extracting** (Archive) * **Downloading** (Restore) ![](https://files.readme.io/6bf8a8e-archive-service-resotre-cancel.jpg) #### Restart an Archive or Restore Process You can restart a failed archive or restore process in the following situations: * The project has **Full Project Lock** activated in Empower. In this scenario, you can either remove the Full Project Lock in Empower or [manually archive the project](#manual-archive). ![](https://files.readme.io/7f8e76c-archive-service-restart-full-lock.jpg) * The project encounters a data integrity issue, but you would like to still archive the project. In this scenario, you can restart the process by selecting `Rerun with project integrity issue ignored`. The Agent then archives the project without raising `Verification Error` again. ![](https://files.readme.io/8a63d70-archive-service-restart.jpg) ### View Audit Trail The TDP has a secure, computer-generated, time-stamped audit trail to independently record the date and time of operator entries and actions that create, modify, or logically delete electronic records. As an **Org Admin** user, you can access the audit trail, filter and view audit trail records, and download them to a CSV for further analysis or record keeping. For more information, see [Audit Trail](https://developers.tetrascience.com/docs/audit-trail). > 📘 NOTE > > To see an Audit Trail entry's logs, select **View Change** in that entry's row on the Audit Trail page in the TDP. > ![](https://files.readme.io/7e02f9e-archive-service-audit-trail-detail.jpg) ### Data Integrity Verification The following sections describe the data integrity verification process for Empower Project data and TDP Archive Project data. #### Empower Project Data Integrity If any data integrity errors occur, the Agent labels the process as an **Integrity Error** in the Tetra Empower Agent Management Console. The Archive Service validates each project's data integrity by using the following resources: | Item | Verification | | ------------------------------------------- | -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | Empower ToolKit | The data integrity error message returned from ToolKit Backup and Restore API calls | | Project Archive Output folder | Verifies that the standard files (as below) generated by the Empower backup process are not missing any of the following:

EXP
INF
EXP.CKS
INF.CKS
Backup.log
Project_Integrity.txt

| | backup.log | Verifies the rows outputted in `CHROMATOGRAM` match with the channel data files in the output folder | | project_integrity.txt | Verifies that there are no data integrity errors for the any channel data, such as `Error: Failed to read good raw datafile with ID 46609` | | Restore the archive project back to Empower | Verify the archived project can be restored back to Empower before removing that project from Empower | > 🚧 IMPORTANT > > The Agent marks archive and restore processes as **Failed** if the `Backup.log` contains Oracle-related errors, such as the following: > > * `EXP-00008: ORACLE error 3113 encountered` > * `ORA-03113: end-of-file on communication channel` > * `EXP-00008: ORACLE error 1041 encountered` > * `ORA-01041: internal error. hostdef extension doesn't exist` > * `EXP-00000: Export terminated unsuccessfully` #### TDP Archive Project Data Integrity The Agent verifies the archived file `checksum` against the `checksum` generated by the TDP. It also ensures the data exists in the TDP before removing the project from Empower. | Operation | Verification | | :-------- | :------------------------------------------------------------------------------------------------------------------------------------------------- | | Archive | Verifies that the file exists in the TDP and that the `checksum` matches with the local, archived project before deleting the project from Empower | | Restore | Recalculates the `checksum` after downloading the archived project from the TDP, and verifies that it matches the `checksum` generated by the TDP | ### Project-Level Labels The Archive Service captures the following labels from the Empower project and Empower software. | Name | Example Value | | :------------------- | :--------------------------------------------------------------------- | | database_name | Database name from Empower | | vendor | Waters Corporation | | instrument_type | CDS - Chromatography Data System | | software | Empower | | pc_name | The Agent's current virtual machine's (VM’s) that it's running on | | project_id | Project name of Empower project (duplicated by `empower_project_name`) | | empower_project_name | Project name of Empower project (duplicated by `project_id`) | | root_project_name | The root project name of the Empower project | | created_by | Who created the project in Empower | | software_version | Empower version | # TDP UI Configuration In [TDP v4.2.0 and higher](https://developers.tetrascience.com/docs/tdp-v420-release-notes#tetra-empower-agent-cloud-configuration), you can use the **Agents** page in the TDP UI to do the following: * [Configure Empower project settings](#configure-empower-project-settings-from-the-tdp-ui) * [Initiate scan requests for Empower projects](#initiate-scan-requests-for-empower-projects-from-the-tdp-ui) > 🚧 IMPORTANT > > To view and configure Tetra Empower Agents in the TDP UI, you must sign in to the TDP as a user with an [**Administrator** role](https://developers.tetrascience.com/docs/platform-roles-and-permissions#administrator-role-permissions). ## Prerequisites Before you can configure the Tetra Empower Agent in the TDP UI, you must do the following: * Upgrade to [TDP v4.2.0 or higher](https://developers.tetrascience.com/docs/tdp-v420-release-notes#tetra-empower-agent-cloud-configuration). * [Create a new Tetra Empower Agent](https://developers.tetrascience.com/docs/centralized-configuration-of-tetra-data-platform-components#create-a-new-agent). * Install the Tetra Empower Agent 5.4.0 or higher on a local host server. For more information, see the [Tetra Empower Agent Installation Guide (v5.4.x)](https://developers.tetrascience.com/docs/tetra-empower-agent-installation-guide-54x). * From the Tetra Empower Agent Management Console, select **Yes** for the **Receive Commands** option. For instructions, see [Verify Connector Settings](https://developers.tetrascience.com/docs/tetra-empower-agent-installation-guide-54x#verify-connector-settings) in the Tetra Empower Agent Installation Guide (v5.4.x). ## Configure Empower Project Settings from the TDP UI To configure Empower project settings from the TDP UI, do the following: 1. [Sign in to the TDP](https://developers.tetrascience.com/docs/sign-in-and-out-of-tdp-and-manage-password) as a user with an **Administrator** role. 2. In the left navigation menu, choose **Data Sources**. 3. Choose **Agents**. The Agents page appears. 4. Select the name of the Tetra Empower Agent that you want to configure. The Agent **Details** page appears. 5. Select the **Configuration** tab. The Agent's configuration information appears. 6. In the **Project Configurations** section, choose the **Edit** button. 7. Configure any of the [available Empower Project settings](#empower-project-settings). 8. Choose **Save Edits**. A dialog appears that asks you to confirm that you want to save your changes. 9. Choose **Update Project** to save the updated settings. > 📘 NOTE > > When new settings are saved through the TDP UI, the Tetra Empower Agent is updated locally. You can verify that the settings were applied by the date/timestamp shown under **Project Configurations**. ![](https://files.readme.io/deb8b29a1f1519e8ccfc14ac36f601d4538cc16eddd2ad0f1e2eb88ef7a56cd5-empower-agent-config-1.png) ### Empower Project Settings You can configure any of the following Empower Project settings in the TDP UI. For more information about each project setting, see [Manage the Empower Projects That the Agent Scans](#manage-the-empower-projects-that-the-agent-scans). | Project Setting | Description | | -------------------------- | ------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | | **ENABLED** | Toggle to disable a project path

Keep in mind the following:

- Only enabled projects appear in the UI. If a project is already disabled, it doesn't appear in the TDP UI.

- If there are nested project(s) in the path that you're disabling, a notification appears and asks if you want all of the child projects disabled, too. To disable all of the path's child projects, choose **Yes**. To maintain the existing configurations for child projects, choose **No**.

- **Auto Enable New Projects** and **Auto Enable New Child Projects** show the state that is configured on the local Agent and can currently only be enabled on the local Agent instance.

- If the Agent scans an Empower project that has a path with more than 260 characters (the [`MAX_PATH` limitation for the Windows API](https://learn.microsoft.com/en-us/windows/win32/fileio/maximum-file-path-limitation?tabs=registry)), the Agent won't record that the file upload succeeded. This behavior results in a race condition that causes the Agent to continue re-uploading the same file, without recognizing that each following upload attempt is also successful. Please contact TetraScience support if you encounter this issue. | | **PRIORITY** | Shows the scan priority assigned to the project (**Not Set**, **Normal**, or **High**). Based on the priority, there are dedicated processes to generate the injections. | | **3D METHOD** | Provides settings to configure which toolkit method will be used to generate 3D MS data cubes (**None**, **Get3D**, or **GetSpectra**), if any injection for the selected project has them. | | **SIGN OFF RESULT OPTION** | Provides the following settings to manage if injection data will be generated by an Agent based on sign-offs performed in Empower (default is **Not Required)**:

- Level 1 Required

- Level 2 Required

- Not Required | ## Initiate Scan Requests for Empower Projects from the TDP UI To initiate scan requests for Empower projects from the TDP UI, do the following: > 📘 NOTE > > To help reduce upload latency, it's recommended that you scan as few paths at the same time as possible. 1. [Sign in to the TDP](https://developers.tetrascience.com/docs/sign-in-and-out-of-tdp-and-manage-password) as a user with an **Administrator** role. 2. In the left navigation menu, choose **Data Sources**. 3. Choose **Agents**. The Agents page appears. 4. Select the name of the Tetra Empower Agent that you want to initiate a scan request for. The Agent **Details** page appears. 5. Select the **Configuration** tab. The Agent's configuration information appears. 6. In the **Project Configurations** section, choose **Scan Projects**. Check boxes appear to the left of each project path name. 7. Select check boxes for up to 10 enabled project paths that you want the Agent to scan. 8. Choose **Scan[#] Projects**. A window appears showing the Empower project path(s) selected for a scan and the last time these projects were scanned. Review that these project paths are all correct. Then, select **Scan Projects** to initiate the scan. 9. In the **Project Configurations** section, review the **Last Manual Scan** column to see the current status of the scan for each path. ![](https://files.readme.io/b01ed04306615f31c5a294a0e2b1cb224ebadf871ab08396e277745f1be3ea48-empower-agent-config-2.png)
